Флексо 8 цветов с центральным барабаном SOMA FLEX mini-uv 2004 г.
- Код: 76
- Цена: 90 000 дол.США
- Год: 2004
- Формат: 850 мм
- Количество отпечатков: -
Описание
Флексо 8 цветов с центральным барабаном SOMA FLEX mini-uv 2004 г.
- The machine hat 15.477 operating hours and has printed 88.651 000 Lm
- Dryer UV
- Pretreatment UV (GEW)
- Camera Tescan
- no of inking units - 8
- Max. Printing width - 800 mm
- Max. Width of the material - 850 mm
- Min. Width of the material - 300 mm
- Minimum length - 300 mm
- Max. length - 600 mm
- Max. Mechanical machine speed - 250 m / min
- Print speed of the standard pressure - 190 m / min
- Tensile force in the printed material - 10 ÷ 360 N
- State of operation - to the left of the winding
- To the central cylinder
- Long axis
- Parameters of unwinding and rewinding reels:
- Max. Roll diameter - 800 mm
- Inside diameter of the cardboard sleeve - 76 mm
- Outer diameter of cardboard sleeve - 105 mm
- Max. weight of the roller - 450 kg
- Min. Roll diameter for NONSTOP unwinding 500 mm
- Max. Speed with roller exchange for
- NONSTOP unwinding - approx. 100 m / min
- Min. Pull in the printed material when changing the reel
- At NONSTOP - 40 N
- Compressed air consumption - 3.4 m3 / h with electr. Feed pumps
- Compressed air consumption for pneumatic feed pumps
- - 8 pieces - 5 m3 / h
- Dimensions (W x L x H) - 3000 x 9500 x 3800 mm
- Mass - about 31 000 kg
Price 90 000 $
